20557501_Line_Drawing_Venting_Kit_GERMANY_de-DE

Siemens HZ9VDKR2 Recirculation Set

Accessories for Cooktops with Integrated Ventilation Module The Siemens HZ9VDKR2 recirculation set is…

Quantity	Unit price
To 1	€89.00*
From 1	€78.00*

Prices incl. VAT plus shipping costs

Available.

instalment payment

14 days Money-back guarantee

97 % rate our store as EXCELLENT

14 days Money-back guarantee If you are not satisfied with the product, simply send it back and we will refund your money.

Product number: HZ9VDKR2

Siemens HZ9VDKR2 Re…

From €78.00*

Product information "Siemens HZ9VDKR2 Recirculation Set"

Accessories for Cooktops with Integrated Ventilation Module

The Siemens HZ9VDKR2 recirculation set is the ideal accessory set for guided recirculation systems for your cooktop with an integrated ventilation module. It is designed to be used in combination with the flat duct elbow already included in the appliance set. The set contains 3 connection collars, a straight flat duct piece (500 mm), and a vertical 90° flat duct elbow for efficient air circulation.

The preferred ducting solution for guided recirculation should only be used with cooktop sets that include at least one flat duct elbow.

Highlights

The set includes:

3 connection collars (female) for combining male flat duct elements
Straight flat duct piece (male, 500 mm)
Vertical 90° flat duct elbow (L radius, male)
Diffuser element (male), which connects with the flat duct elements and distributes the exhaust air in the plinth area for guided recirculation configurations.

These components enable installations in countertop heights up to 960 mm. The accessory set complies with the needle-flame test (per IEC 60695-11-5) and meets the B1 building material classification (per DIN 4102).

Technical Data

Dimensions of the packaged product: 175 x 400 x 595 mm
Pallet dimensions: 103.5 x 80.0 x 120.0 cm
Number of units per pallet: 20
Net weight: 2.0 kg
Gross weight: 3.1 kg
